VLX 100 Arched / Custom Door

VLX 100 Arched / Custom Door in Jacksonville, FL | Meridian Windows and Doors Jacksonville

An arched entry door changes how a home meets the street. The VLX 100 Arched / Custom Door from ViewLux does that with CNC-bent aluminum that holds a true, clean curve, no sagging, no distortion. Meridian Windows and Doors Jacksonville is an authorized installation partner for ViewLux, which means you get the product exactly as engineered, installed to AAMA standards. We’ve fitted these doors on custom builds in Ortega, mid-century remodels in San Marco, and coastal properties in Atlantic Beach. If you’re considering an arched or fully custom entryway in Jacksonville, FL, call us at (904) 513-9670 to talk through what’s possible.

Call (904) 513-9670

Product Overview – VLX 100 Arched / Custom Door

The VLX 100 is not a flat door bent into a curve. Each unit is fabricated from aluminum that’s CNC-bent to the exact radius you specify, so the arc is consistent from jamb to jamb and the panel seats flush every time. That structural precision is why architects in Jacksonville, FL keep specifying this series for custom entryways, wine rooms, and interior passage doors where a standard rectangle would flatten the design.

What makes the series stand out is the marriage of a 0.098-inch wall thickness with a 2.56-inch profile width. That wall thickness gives the frame real torsional rigidity, which matters on a tall arched door where wind and humidity are constant pressures. The profile width keeps sightlines slim enough for contemporary work but substantial enough to feel like a proper front door, not a storefront system.

Buyers choose this door when they’ve been told by other companies that an arch “can’t be done” or will cost more than the budget allows. We’ve been installing ViewLux products across Jacksonville long enough to know those limitations usually come from the installer, not the product. The VLX 100 is fabricated to order, which means the span is whatever your opening actually is, not whatever a stock catalog happens to offer.

In Jacksonville, FL, a custom arched door also has to survive more than aesthetics. Summer thunderstorms, hurricane season wind loads, salt air near the beaches, and 90 percent humidity are working against an entry door every single day. The VLX 100 is built for that reality, not just photographed for a portfolio.

Technical Specifications

Here’s what the VLX 100 Arched / Custom Door brings to the table, in plain terms:

• Wall thickness: 0.098 inches. That’s heavier than most residential aluminum door frames, and it’s what gives the curved members their rigidity over long spans.
• Profile width: 2.56 inches. A balanced sightline that works on both modern and traditional elevations.
• Maximum span: Custom fabricated to order. You’re not picking from preset sizes, so the arch can match an existing opening or a new one drawn by your architect.
• Glass options: Clear, Frosted, Obscure, Low-E, Tempered, Laminated. Mix and match depending on privacy, energy, and impact needs.
• Finish options: Premium Black, Pure White, Anodized Silver, Bronze, Champagne, Teak Wood. Powder-coated or anodized depending on the finish you select.

Every VLX 100 we install in Jacksonville goes out with thermally broken framing, which is standard practice for us but still not a given on every aluminum door sold in the market.

Performance Features

Thermal Efficiency. The VLX 100 frame includes a thermal break that separates interior and exterior aluminum, which cuts heat transfer through the frame itself. Paired with Low-E glass, an arched entry door doesn’t have to be an energy liability. NFRC-rated performance means the numbers are real, not marketing.

Acoustic Performance. Aluminum is dense, and a 0.098-inch wall absorbs sound better than thinner residential frames. Laminated glass adds another layer of noise reduction, which matters if your Jacksonville home sits near San Jose Boulevard, I-95, or a school zone.

Airtightness & Weather Seal. Every perimeter joint on our Jacksonville installations gets AAMA 812 low-expansion foam sealant, which stops air from sneaking around the frame. That’s the difference between a door that leaks on day one and one that’s still tight five years later.

Waterproofing. Florida rain is not gentle. The VLX 100’s sill and frame design routes water away from the threshold, and our installation process includes a final water test before we call the job done. Mist prevention and water resistance are engineered into the system, not patched on after the fact.

Wind Resistance. Jacksonville sits in a high-velocity hurricane zone, and a large arched door is a big wind target. The VLX 100 is wind-load rated for local climate requirements, and the laminated glass option gives you impact resistance for coastal or exposed sites.

Security & Hardware. A front door is a security boundary. The aluminum frame depth on the VLX 100 accepts multipoint locking hardware, and the rigidity of the bent aluminum means the panel won’t flex out of the lock’s reach over time the way thinner frames can.

Color & Glass Options

The finish you choose sets the tone before anyone steps inside. Premium Black reads sharp and modern, and it’s the finish we see most in Avondale and Riverside on renovated bungalows that want a contemporary edge. Pure White suits coastal and cottage styles, and it holds up well against the bright Florida sun without yellowing. Anodized Silver is a true aluminum look, clean and commercial but at home on mid-century homes in San Marco. Bronze warms up the entry and hides fingerprints better than darker tones. Champagne is subtler than gold and works beautifully on Mediterranean-style homes in Jacksonville, FL. Teak Wood gives you the look of timber without rot, termites, or repainting every three years, which is a serious advantage in this climate.

Glass choice depends on what the door faces. Clear glass maximizes natural light into a foyer. Frosted and obscure glass give privacy for doors that face the street. Low-E cuts solar heat gain, which matters on west-facing entries in the Florida afternoon. Tempered glass is code-required in doors and adds safety. Laminated glass adds impact resistance and sound damping, the right choice for a door within a mile of the coast or near a noisy corridor. We help you pick the right combination when we measure the opening in person.

Installation by Meridian Windows and Doors Jacksonville in Jacksonville

A custom arched door installed poorly is worse than a stock door installed well. The curve magnifies any mistake: a frame out of level shows immediately, a plumb error makes the door bind at the top of the arc, and a bad seal leaks at the threshold after the first Jacksonville summer storm.

Our install process starts with a pre-install inspection of the rough opening. Custom arched openings have to be framed right before the door ever arrives, and we check that before ordering. When the VLX 100 arrives from ViewLux, we set the frame level, plumb, and square, using shims and checking the arc at multiple points along the curve. That’s the part where lazy crews rush.

We seal every perimeter joint with AAMA 812 low-expansion foam, which keeps the seal intact as aluminum expands and contracts through Jacksonville, FL temperature swings. The installation follows AAMA 2400/2410 standards, which govern the proper installation of windows and doors in residential and light commercial work. After the door is set and the glass is in, we run a water test on the sill and jambs, clean the job site, and walk you through operation and care.

One thing to know: ViewLux’s manufacturer warranty is contingent on proper installation. If a door is installed by someone who doesn’t follow AAMA standards, the warranty is at risk. Meridian Windows and Doors Jacksonville installs to the standards the manufacturer requires, so your warranty stays intact. In Jacksonville, FL, we also account for local codes on wind load and impact requirements, and we’ll tell you if your door needs laminated glass to pass inspection.

Frequently Asked Questions – VLX 100 Arched / Custom Door

What is the lead time for the VLX 100 Arched / Custom Door? Lead time is typically 8 to 12 weeks from final measurements and deposit because each unit is custom fabricated to order. Call (904) 513-9670 and we’ll give you a current production timeline based on your spec.

Does the VLX 100 qualify for energy tax credits? It depends on the glass package specified. Low-E glazing options and the thermally broken frame contribute to energy performance, and we can help you identify which configurations meet current federal or utility rebate requirements in Jacksonville, FL. Call (904) 513-9670 to discuss your project.

What warranty comes with the Arched / Custom Door? ViewLux provides a manufacturer’s warranty on the door, and that warranty remains valid when installation is completed per AAMA standards by an authorized partner like Meridian Windows and Doors Jacksonville. We can review warranty coverage for your specific configuration before you order.

Can I customize the size of the VLX 100 Arched / Custom Door? Yes. The series is fabricated to order, so the arch radius, height, and width are built to your opening rather than pulled from stock sizes. That’s the whole point of going custom. Call (904) 513-9670 to schedule a measurement.

How do I maintain aluminum frames in Florida’s climate? Wash the frames with mild soap and water twice a year, keep sill drainage channels clear of debris, and check the weatherstripping annually. Aluminum doesn’t rot or warp like wood, and the finishes on the VLX 100 are built for sun exposure. Don’t use abrasive cleaners on the finish.

Get a Quote – VLX 100 Arched / Custom Door in Jacksonville

If you’re planning an arched entryway or a custom door that’s been turned down elsewhere, let’s talk. Meridian Windows and Doors Jacksonville will measure your opening, spec the right glass and finish, and install the VLX 100 to AAMA standards. Call (904) 513-9670 to start your project or schedule a free on-site measurement in Jacksonville, FL.

Written by the team at Meridian Windows and Doors Jacksonville, authorized ViewLux installation partner serving Jacksonville, FL.
